Base cabinet one door and 2 shelves


Item no.: 081611
EAN: 4033592151689


Information about the product

Description

  • Extra strong, 1 mm thick fronts for maximum robustness
  • Design handle strip, ergonomically optimised
  • Automatic hinges with integrated damping
  • Elastomer-mounted central locking system for convenient operation, integrated in the frame
  • No annoying keys in the door
  • Double-walled, noise-insulated door, 100° opening angle Stops with rubber buffers
  • Shelves can be loaded up to 100 kg
  • Design body with double-reinforced side panels
  • 2 cable grommets and ventilation at the rear of the cabinet
  • Height-adjustable feet with hexagon socket for quick adjustment
  • Quick connection and centring of the modules via 2 screw connections Removable skirting board for energy management and cleaning
  • Optional skirting lighting

Technical data

Weight [kg] 48
Height [mm] 980
Width [mm] 689
Depth [mm] 550

More images

Detailed images

Application images

Accessories

Item no. variant Name
085004 - Shelf 600 with accessories
50825L - Industry bench vise, 125 mm jaw width

Spare and wear parts

Item no. variant Name
085053 - Hinge inset 2-piece
085055 - Lock 90° with key 601
085057 - Adjustable feet, 4-piece
085058 - Skirting board for base cabinet
